Flow Heaters
The Kanthal® Flow Heater is designed to heat air and process gases to
temperatures up to 1,100°C (2,012°F) with unmatched precision and efficiency.
Its robust design and superior performance make it ideal for integration into
machines and installations. The Kanthal® Flow Heater is suitable for continuous
and cycling operations.
The Kanthal® Flow Heater is available in multiple power options, including 3.5
kW, 11 kW, 20 kW, 30 kW, 40 kW, and 60 kW, catering to different heating
requirements.
Industries
- Local heat treatment.
- Aluminum (primary and secondary processing).
- Glass manufacturing.
- Power-to-X applications.
- Packaging.
- Research and Development (R&D).
Industries
Information
With a unique design and robust internal temperature control, the Kanthal® Flow Heater can deliver gas outlet temperatures of up to 1,100°C (2,012°F), compared with 800°C (1,470°F) in conventional air heaters, as well as a temperature accuracy within ±1°C. When it comes to drying and preheating processes, flow heaters can deliver the same performance as gas burners but with increased heat efficiency. They can also reduce the CO2 footprint and eliminate combustion-related pollutants such as NOx and SOx from processes or facilities.
Characteristics
Key Features
- Highest outlet temperatures [(1,100°C) (2,012°F)] due to unique patented design
- Power density comparable with gas burners
- Excellent outlet temperature accuracy (± 1 °C / F)
- Internal thermocouple for secure over temperature protection and controls
- Wide flow rate range: 20 – 200 % of nominal flow rate (or higher with custom Flow Heaters)
- Empower your Flow Heater with well-matched original accessories like control cabinets, blowers and custom tubing and insulation solutions
- Small in feature size
- Pulsating flow can be tolerated by the heater
- Custom designs upon request
